.NET 8 vs .NET 10: Benchmarking FFT, I/O, Image Processing, JSON, and LINQ

.NET 8 vs .NET 10: Benchmarking FFT, I/O, Image Processing, JSON, and LINQ 🚀

Performance improvements are easy to talk about and hard to validate. With .NET 10 arriving, I wanted to understand what actually changed at the runtime level, not what looks good in release notes.

This article continues my .NET 8 vs .NET 10 benchmarking series and focuses on workloads that appear in real systems but often get ignored:

Fast Fourier Transform (FFT)

File I/O

Image processing

JSON processing

LINQ and parallel execution

Same code. Same inputs. Same machine.

Only the runtime changes.

🧪 Benchmark Configuration

All benchmarks were executed using BenchmarkDotNet, which automatically adjusts iteration counts based on execution time:

Nanoseconds: ~100 iterations

Microseconds–milliseconds: ~15–50 iterations

Seconds: ~10–15 iterations

Test Parameters

Threading: 10,000 tasks per test

Matrix operations: 100×100

BigInteger: 4096-bit numbers

Prime generation: first 10,000 primes

Image processing: 3840×2160 (4K)

WebSocket: 10–100 messages per connection

JSON: nested objects up to 10 levels

LINQ: 10,000-element collections

🔊 Fast Fourier Transform (FFT)

FFT workloads are common in signal processing, audio analysis, and scientific computing.

Results Summary

Cooley–Tukey FFT: +3.4% faster

Naive DFT: -2.0% slower

Optimized FFT algorithms benefit slightly from runtime improvements, while naive implementations remain largely unchanged.

Takeaway:

FFT improvements exist, but they are incremental. If FFT performance is critical, algorithm choice still matters more than runtime version.

💾 File I/O Benchmarks

This benchmark writes and reads a 100 MB file.

Results Summary

FileWriteRead: -1.1% This is effectively noise.

Disk and filesystem latency dominate here, not the runtime.

Takeaway:

If your application is I/O-bound, upgrading the runtime won’t magically make it faster. Focus on buffering, async I/O, and storage choices instead.

🖼 Image Processing

Image processing benchmarks are extremely sensitive to memory access patterns, CPU cache behavior, and instruction selection.

Results Summary

3×3 convolution: -4.2%

5×5 convolution: -5.6%

7×7 convolution: -39.7%

The larger the kernel, the bigger the regression.

Why this happens:

Small runtime changes can significantly affect cache locality and vectorization. Larger convolution kernels amplify these effects.

Takeaway:

If your application does heavy image processing, you should benchmark carefully before upgrading.

📦 JSON Processing

This is where .NET 10 clearly stands out 💥

Results Summary

Newtonsoft deep nesting: +20.9%

Newtonsoft JObject modification: +17.2%

Span-based deserialization: +22.3%

System.Text.Json deep nesting: +27.1%

JsonNode modification: +23.8%

Streaming JSON: +28.9%

Allocations mostly stayed flat, which makes these wins even more impressive.

Takeaway:

If your system handles APIs, events, logs, or message pipelines, JSON performance gains alone may justify upgrading.

🔗 LINQ and Parallel Operations

LINQ remains one of the most complex areas to optimize.

Results Summary

Compiled expressions: +20.6%

Nested joins (LINQ): +15.8%

Nested joins (manual): +20.9%

PLINQ CPU workloads: +16.4%

Parallel.ForEach CPU: +4.1%

Direct delegate invocation: -3.7%

SelectMany LINQ: -39.5%

Some paths improved dramatically. Others regressed just as dramatically.

Why this matters:

LINQ performance depends heavily on query shape, nesting depth, and execution strategy. One optimization can help some scenarios while hurting others.

Takeaway:

LINQ users should benchmark their real queries, not assume global improvements.

🧠 Final Thoughts

These benchmarks reinforce a few important truths:

.NET 10 brings real, measurable improvements

Gains are highly workload-dependent

Some regressions are unavoidable and must be measured

JSON and many LINQ paths are clear winners

I/O remains mostly unchanged

There is no universal answer to “Is .NET 10 faster?”

The only honest answer is: It depends on what you run.

If performance matters in your system, run your own benchmarks. Numbers from your workload will always beat numbers from mine.

Happy benchmarking 🔍
